SP 5A-25 R [5991925]
SP 5A-25 R [5991925]
Grundfos
Normale prijs
€3.636,09 EUR
Normale prijs
€5.427,00 EUR
Aanbiedingsprijs
€3.636,09 EUR
Eenheidsprijs
/
per
Prijs exclusief BTW.
Verzendkosten worden berekend bij de checkout.
Kan beschikbaarheid voor afhalen niet laden
Submersible borehole pump, suitable for pumping clean water. Can be installed vertically or horizontally. All steel components are made in high-grade stainless steel, EN 1.4539 (AISI 904L), that ensures high corrosive resistance. This pump does not carry drinking water approval.
Specs Table
| Vloeistof: | |
| Te verpompen medium: | Water |
| Bereik vloeistoftemperatuur: | -15 .. 40 °C |
| Medium temperatuur tijdens bedrijf: | 20 °C |
| Dichtheid: | 998.2 kg/m³ |
| Technisch: | |
| Pompsnelheid waarop pompgegevens zijn gebaseerd: | 2900 omw/min |
| Nominaal debiet: | 5 m³/u |
| Nominale opvoerhoogte: | 102 m |
| Goedkeuringen: | CE,EAC,UKCA,SEPRO,MOROCCO |
| Goedkeuringen voor motor: | CE,EACMOROCCO,UKCA,SEPRO,RCM |
| Curve tolerantie: | ISO9906:2012 3B |
| Motor version: | T40 |
| Terugslagklep: | YES |
| Specificaties aseinde: | CYLINDRICAL |
| Materialen: | |
| Pomp: | Stainless steel |
| EN 1.4539 | |
| ASTM A240 | |
| Waaier: | Roestvast staal |
| EN 1.4539 | |
| AISI 904L | |
| Motor: | Stainless steel |
| EN 1.4539 | |
| Asafdichting: | SiC/SiC |
| Installatie: | |
| Maximale omgevingsdruk: | 60 bar |
| Maximale bedrijfsdruk: | 60 bar |
| Maximaal toelaatbare uitlaatdruk: | 16.3 bar |
| Type aansluiting: | Rp |
| Maat van de aansluiting: | 1 1/2 inch |
| Motor diameter: | 4 inch |
| Minimale diameter van boorgat: | 105 mm |
| Elektrische gegevens: | |
| Motor type: | MS4000 |
| Ontwerp motorflens: | Grundfos |
| Nominaal vermogen - P2: | 2.2 kW |
| Vermogen (P2) benodigd voor pomp: | 2.2 kW |
| Netfrequentie: | 50 Hz |
| Nominale spanning: | 3 x 380-400-415 V |
| Nominale stroom: | 6-6-6.3 A |
| Startstroom: | 420-440-450 % |
| Cos phi - krachtfactor: | 0.8-0.74-0.69 |
| Nominale snelheid: | 2850-2860-2880 omw/min |
| Aanloopmethode: | Direct-on-line (DOL) |
| Dichtheidsklasse (IEC 34-5): | IP68 |
| Isolatie klasse (IEC 85): | F |
| Ex-beveiligingsrichtlijn: | GEEN |
| Thermische beveiliging: | External |
| Ingebouwde temp. opnemer: | Yes |
| Kabellengte: | 1.7 m |
| Type kabel: | FLAT |
| Motor Nr.: | 7C193707 |
| Windings: | Enameled |
| Overige: | |
| Minimale Efficiëntie Index, MEI ≥: | 0.50 |
| Netto gewicht: | 27.3 kg |
| Bruto gewicht: | 29 kg |
| Transportvolume: | 0.021 m³ |
| Milieukeurmerken: | WEEE |
