SP 5A-9 N [5200009]
SP 5A-9 N [5200009]
Grundfos
Normale prijs
€803,33 EUR
Normale prijs
€1.199,00 EUR
Aanbiedingsprijs
€803,33 EUR
Eenheidsprijs
/
per
Prijs exclusief BTW.
Verzendkosten worden berekend bij de checkout.
Kan beschikbaarheid voor afhalen niet laden
Submersible borehole pump, suitable for pumping clean water. Can be installed vertically or horizontally. All steel components are made in stainless steel, EN 1.4401 (AISI 316), that ensures high corrosive resistance.
Specs Table
| Vloeistof: | |
| Te verpompen medium: | Water |
| Bereik vloeistoftemperatuur: | -15 .. 60 °C |
| Medium temperatuur tijdens bedrijf: | 20 °C |
| Dichtheid: | 998.2 kg/m³ |
| Technisch: | |
| Pompsnelheid waarop pompgegevens zijn gebaseerd: | 3450 omw/min |
| Nominaal debiet: | 6 m³/u |
| Nominale opvoerhoogte: | 53 m |
| Goedkeuringen: | CE,EAC,UKCA,SEPRO,MOROCCO |
| Curve tolerantie: | ISO9906:2012 3B |
| Terugslagklep: | YES |
| Specificaties aseinde: | CYLINDRICAL |
| Materialen: | |
| Pomp: | Stainless steel |
| EN 1.4401 | |
| AISI 316 | |
| Waaier: | Roestvast staal |
| EN 1.4401 | |
| AISI 316 | |
| Installatie: | |
| Maximale bedrijfsdruk: | 15 bar |
| Maximaal toelaatbare uitlaatdruk: | 5.9 bar |
| Type aansluiting: | Rp |
| Maat van de aansluiting: | 1 1/2 inch |
| Motor diameter: | 4 inch |
| Minimale diameter van boorgat: | 105 mm |
| Elektrische gegevens: | |
| Ontwerp motorflens: | Grundfos |
| Vermogen (P2) benodigd voor pomp: | 1.1 kW |
| Overige: | |
| Minimale Efficiëntie Index, MEI ≥: | 0.50 |
| Netto gewicht: | 5.7 kg |
| Bruto gewicht: | 6.8 kg |
| Transportvolume: | 0.011 m³ |
